CF8368 Plastic Smoke Density Tester Machine AC200V-240V 50Hz

Packaging Details : Wooden cases

Supply Ability : 5 units per month

Price : US$2000-$30000

Place of Origin : China

Brand Name : CHENGFENG

Certification : ISO,CE

MOQ : 1 Set

Delivery Time : 10 Work Days

Payment Terms : T/T,Cash,L/C,Western Union,MoneyGram

warranty : 1 year

Gas source : Purity of 95%, propane and air mixed gas

Propane flow meter : 1-100cm³/min

Air flow meter : 5~500cm³/min

Translucency resolution : 0.0001%

Measurement accuracy : ± 3%

Working voltage : AC200-240V 50Hz

Environmental humidity : room temperature -40 ℃

Working environment : avoid direct sunlight , should be no forced air flow.

Heat flow meter : A flat area with a range of 50kw/㎡

Contact Now

CF8368 Plastic Smoke Density Tester Suitable For Measuring Smoke

CF8368 Plastic Smoke Density Tester Machine AC200V-240V 50Hz

Scope of application: Suitable for measuring the specific optical density of smoke generated during plastic combustion, and taking the maximum specific optical density as the test result. It is used to evaluate the smoking performance of plastics under specified conditions.



The plastic smoke density tester is a new type of testing equipment developed based on the technical conditions specified in the standard GB/8323.2-2008 and ISO5659-2 "Plastic smoke generation - Part 2: Single chamber method for measuring smoke density".



Main parameters: The entire instrument consists of a closed test chamber, a photometer measurement system, a radiation cone, a combustion system, an igniter, a test box, a bracket, a temperature measuring instrument, and smoke density testing software; The circuit is developed using a microcontroller, with high technical content and stable performance. This instrument is suitable for all plastics and can also be used for the evaluation of other materials (such as rubber, textile coverings, painted surfaces, wood, and other materials). It is widely used in production factories and research and testing units in the plastic and solid materials industries.



Our Services

1. Ensure the high quality of the product.

2. Packaging can be done according to customer requirements and pictures can be attached before shipment.

3. Transport professional documents

4. Provide professional product consultation before sales, and we guarantee to answer any professional technical questions you may have within 48 hours; Provide timely product technical services after sales, and provide solutions within three working days.

5. Our engineers provide professional after-sales service

6. The warranty period is 12 months. During the warranty period, we are responsible for providing free maintenance, upkeep, and replacement of damaged and defective parts (under normal use) for the user's equipment. After the free warranty ends, service fees will be charged at your discretion.

7. Provide the fastest response to maintenance and assistance requests from users. After the user submits a maintenance request, ensure to provide professional technical support in the shortest possible time and in the fastest way possible.
